0.25 Mm End Emitting Plastic Optical Fiber

Description TXPOF PMMA plastic optical fiber TX-FL0250 0.25mm end emitting plastic polymer optic fiber star ceiling fiber PMMA fiber, also known as plastic optical fiber (POF). It's a kind of fiber made from polymer. Light is transmitted by reflection in optical fibers and it's end glow....

Send Inquiry Chat Now

Product Introduction

0.25mm end emitting plastic polymer optic fiber star ceiling fiber

Description

TXPOF PMMA plastic optical fiber TX-FL0250

0.25mm end emitting plastic polymer optic fiber star ceiling fiber

PMMA fiber, also known as plastic optical fiber (POF). It's a kind of fiber made from polymer. Light is transmitted by reflection in optical fibers and it's end glow. Our FL series POF is mainly used for lighting decoration or data transmission.

Specifications

•Configuration: Simplex

•Core Diameter: 0.25mm

•Core Material: PMMA (Polymethyl Methacrylate)

•Numerical Aperture: 0.5

•Attenuation: 0.35 dB/m at 650 nm

•Operating Temperature Range: -55°C to 70°C

•RoHS/REACH Compliant

FL series end emitting fibers range in diameter from 0.25mm to 3.0mm.

Part Number	Diameater (mm)	Spool Length (meters)	Attenuation (dB/km)
TX-FL-0250	0.25 mm	12000	≤350
TX-FL-0500	0.5 mm	6000	≤270
TX-FL-0750	0.75 mm	2700	≤240
TX-FL-1000	1.0 mm	1500	≤240
TX-FL-1500	1.5 mm	700	≤240
TX-FL-2000	2.0 mm	350	≤240
TX-FL-2500	2.5 mm	250	≤240
TX-FL-3000	3.0 mm	150	≤240

0.25mm end emitting plastic polymer optic fiber star ceiling fiber (1)

Characteristics:
1. Safe, transmit light only, no conductivity or heat transferring.
2. Being able to transmit visible light but not ultraviolet or infrared.
3. Easy installation and maintenance.
4. Good flexibility,stable performance, anti-aging, long life span.
5. Strongest light effect at the end of the fiber.

Shipment

Smaller shipment / urgent shipment

by international express

Freight prepaid or collected

Mass Goods

shipped by sea, by air, by railway

we are close to Shanghai port, Ningbo port

0.25mm end emitting plastic polymer optic fiber star ceiling fiber (5)
