4.4mm Plastic Optical Fiber Cable
◇ Fiber core material: PMMA
◇ Cladding material: Fluorinated Polymer
◇ Jacket: PE/PVC
◇ Optical structure: Step
Product Introduction
Specification
◇ Fiber core material: PMMA
◇ Cladding material: Fluorinated Polymer
◇ Jacket: PE/PVC
◇ Optical structure: Step
◇ Numerical apertuer: 0.5
◇ Core refrective index: 1.49
Features
◇ Light-weight, flexible, high resist flutter and determinate cleavage, durability
◇ Optimum bandwidth, high and stable transmission speed
◇ Waterproof , damp-proof , anti-magnetic , free of magnetic and thunder
◇ lower cost for maintenance , saving cooper resource , energy-saving and environment protection
◇ Immune to electromagnetic wave radiation, no noise effect, good capacity of resisting disturbance
Sheathed with PE jacket for the first time, PVC or other jacket material are sheathed on the POF as the second jacket, better anti-crunch, anti-stretch, anti-grinding, and anti-aging performances, extending operation life, it it applies to many fields. Unique tight jacket adopted in the cable, it is hard to flex during processing or using, and easy to peel off a little jacket meanwhile. The advantage of our plastic optical cable is strong transmission bandwidth, anti-electromagnetic interference, stable & reliable signal transmission.
Model | Core (mm) | OD (mm) | Attenuation (dB/km) | Jacket Material | Meters/roll （meter） | Temperature （℃） |
TX-CC0500-1B | 0.5mm×1 | 1.0mm±0.15 | ≤250 | PE | 1500/5000 | -55~70 |
TX-CC0500-1B/1.25 | 0.5mm×1 | 1.25mm±0.15 | ≤250 | PE | 1500/5000 | -55~70 |
TX-CC0750-1B | 0.75mm×1 | 2.2mm±0.07 | ≤200 | PE | 2500 | -55~70 |
TX-CC1000-1B/1.25 | 1.0mm×1 | 1.25mm±0.15 | ≤200 | PE | 1500/5000 | -55~70 |
TX-CC1000-1B | 1.0mm×1 | 2.2mm±0.07 | ≤200 | PE | 2500/5000 | -55~70 |
TX-CC1000-1A | 1.0mm×1 | 2.2mm±0.07 | ≤180 | PE | 2500/5000 | -55~70 |
TX-CC1500-1/3.0 | 1.5mm×1 | 3.0mm±0.1 | ≤240 | PE/PVC | 700 | -55~70 |
TX-CC2000-1/3.8 | 2.0mm×1 | 3.8mm±0.1 | ≤240 | PE/PVC | 350 | -55~70 |
TX-CC3000-1/4.5 | 3.0mm×1 | 4.5mm±0.1 | ≤240 | PE/PVC | 150 | -55~70 |
TX-CC3000-1/5.0 | 3.0mm×1 | 5.0mm±0.1 | ≤240 | PE/PVC | 150 | -55~70 |
TX-CC1000-2B | 1.0mm×2 | 2.2/4.4mm±0.1 | ≤200 | PE | 1250 | -55~70 |
TX-CC1000-2A | 1.0mm×2 | 2.2/4.4mm±0.1 | ≤180 | PE | 1250 | -55~70 |
TX-CC1000-2B/6.0 | 1.0mm×2 | 2.2/4.4/6.0mm | ≤200 | PE+PVC | 500 | -55~70 |
TX-CC1000-2A/6.0 | 1.0mm×2 | 2.2/4.4/6.0mm | ≤180 | PE+PVC | 500 | -55~70 |
TX-CC1000-2C/6.0 | 1.0mm×2 | 2.2/4.4/6.0mm | ≤200 | PE+PVC | 300 | -55~70 |
TX-CC1000-2B/6.0 | 1.0mm×2 | 2.2/4.4/6.0mm | ≤180 | PE+PVC | 300 | -55~70 |
TX-CC1000-2KB/6.0 | 1.0mm×2 | 2.2/4.4/6.0mm | ≤200 | PE+PVC+kevlar | 300 | -55~70 |
TX-CC1000-2KA/6.0 | 1.0mm×2 | 2.2/4.4/6.0mm | ≤180 | PE+PVC+kevlar | 300 | -55~70 |
TX-CC1000-1BV | 1.0mm×1 | 2.2mm±0.07 | ≤200 | VW-1 | 2500 | -55~70 |
TX-CC1000-1AV | 1.0mm×1 | 2.2mm±0.07 | ≤180 | VW-1 | 2500 | -55~70 |
TX-CC1000-2BV | 1.0mm×2 | 4.4mm±0.1 | ≤200 | VW-1 | 1250 | -55~70 |
TX-CC1000-2AV | 1.0mm×2 | 4.4mm±0.1 | ≤180 | VW-1 | 1250 | -55~70 |
TX-CC1000-1B/4.0 | 1.0mm×1 | 4.0mm±0.1 | ≤200 | PE+PVC | 1000 | -55~70 |
TX-CC1000-1B/5.0 | 1.0mm×1 | 5.0mm±0.1 | ≤200 | PE+PVC | 500 | -55~70 |
Shipment
Mass Goods shipped by sea, by air, by railway we are close to Shanghai port, Ningbo port | smaller shipment / urgent shipment by international express Freight prepaid or collected |
