24 Core Fiber Optic Cable
TX POF is a high performance optical fiber available in both simplex and multicore variants.
Product Introduction
FEATURES:
1. Cost‐effective, rugged optical links
2. Flameproof to UL grade VW‐1
3. Available in reels for on‐site installation, or for making complex harnesses
4. Suitable for use with POF transceivers, including Avago ,TOCP ,SMA ,ST connectors.
Specifications：
Cladding Diameter/ Fiber Core Material: 1000µm / PMMA
Jacket Diameter/ Jacket Material: 3-18mm
Number of fiber :1-150 pieces
Minimum Bend Radius:25mm
Tensile strenght:70N
Transmission Loss: ≤ 180 dB/km @650nm
Numerical Aperture: 0.5NA
Core Refractive Index:1.49
Temperature Range:-55°C to +70°C
Customization: customized logo on the cable
RoHS/REACH Compliant
DESCRIPTION:
1.High Transmission, Low Loss
2. Lowest Attenuation Possible for a Plastic Fiber Optic
3. Ideal for Data Transmission Applications
4.These fibers were designed to provide optimal light transmission in the visible region of the spectrum for both digital and analog data links. They have the lowest attenuation possible for a plastic fiber optic. In addition to data transmission, they can be used for a wide variety of applications wherever superior light transmission is required. They feature increased durability and heat resistance.
